Mid-low latitudes, suitable for agricultural PV projects or mountainous terrain etc.
Designed and Manufactured to suit your location.
NB: Ground Maintenance & Slashing will be Expensive unless Racking is installed to provide at least 200cm when Racking is Horizontal to the Ground at Midday.
Product Features
Less pylons per MW ≤392 (48 per 360 panel array)
One-beam structure, easier for module installation.
Modular triangular structure, improved stability.
Point to point monitoring, real-time monitoring of each tracker.
Plug-and-Play, easier for installation and maintenance.
Technical Parameters
Tracking Type
Long-span Single-Axis Horizontal Tracker.
Number of Panels (DC Power)
6 Rows x 60 panel unit =360 panel Array x 350W =126kW Array.
System Weight
1MW=60TM, without modules & foundation
Corrosion Protection
Hot-Dip Galvanization or Magnesium Alloy Coated Steel.
Power Supply
240V AC
Drive Type Power
Linear actuator (150W DC)
Daily Power Consumption
0.026kWh
Max. Wind Load at Stow Position
Standard 47m/s 170kph (105MPH)
Working Temperature
-30℃~+60℃
Tracking Angle Range
±45° (Max. ±60°)
Control System
perceives solar / wind signals from sensors and transfers those signals to “Slew Drive”
and “Actuator”
